Stainless Steel Green Facade

» 綠色外牆 » Stainless Steel Green Facade

    • Stainless Steel Green Facade

    類別和標籤:
    綠色外牆
    • 材料: High-grade AISI 304, 316, 或316L不銹鋼.
    • Cable Structure: 7×7 or 7×19 configurations.
    • 威吔繩直徑: 範圍從 1.2 mm至 5.0 毫米.
    • Mesh Aperture Sizes: Available from 20 mm × 20 mm up to 200 mm × 200 毫米.
    • 網格形狀: 鑽石 (rhombus) pattern with a standard 60° angle.
    • Connection Types: Ferrule or knotted interwoven mesh.
    • Surface Treatments: Options include natural finish, black oxide, or green powder coating.
    • 抗張強度: Approximately 100,000–110,000 PSI.
    • 斷裂載荷: Varies by configuration, e.g., 676 lbs for 5/64″ (2.0 毫米) wire.
    • 海關編碼: 7314140000.
    詢問
    • 規格

    BMP嘅, a leading Stainless Steel Green Facade factory, provides eco-conscious architects and builders with a durable and beautiful solution: Stainless Steel Rope Mesh Green Wall systems.

    This green wall mesh is made of inter-woven or ferrule stainless steel cables, forming a diamond grid to support climbing plants. It is used to create vertical gardens, improve energy efficiency, reduce pollution, and transform concrete facades into natural landscapes.

    Stainless Steel Green Facade are becoming a global trend in urban greening. They work in private homes, commercial complexes, and public buildings.

    🛠 BMP Stainless Steel Green Facade

    • 網格類型: 鑽石
    • 材料: AISI公司 304 / 316 不銹鋼
    • Cable Structure: 7×7 and 7×19
    • 線徑: 1.2 mm – 3.2 毫米
    • 網格孔徑: 20 × 20 mm至 76 × 76 毫米
    • Standard Mesh Angle: 60° – 90°
    • 完成: Natural, black oxide, or green powder coated
    • Usage Life: Over 30 年
    • 抗張強度: 100,000–110,000 PSI

    📐 Complete Specification Table Stainless Steel Green Facade

    法典 繩索結構 繩索直徑 孔徑 (毫米) 海關編碼 價格 (USD/m²)
    SSGW-01 7 × 7 1.2 毫米 25 × 25 7314140000 $18.50
    SSGW-02 7 × 7 1.6 毫米 38 × 38 7314140000 $17.80
    SSGW-03 7 × 7 2.0 毫米 51 × 51 7314140000 $16.80
    SSGW-04 7 × 7 2.4 毫米 20 × 20 7314140000 $19.50
    SSGW-05 7 × 7 3.2 毫米 76 × 76 7314140000 $15.50
    SSGW-06 7 × 19 3.2 毫米 60 × 60 7314140000 $15.80
    SSGW-07 7 × 19 1.6 毫米 51 × 51 7314140000 $17.60
    SSGW-08 7 × 19 1.2 毫米 25 × 25 7314140000 $18.20

    🌱 Applications of Stainless Steel Green Facade

    • Urban vertical gardens
    • Residential or office building facades
    • Public parks, libraries, 同博物館
    • Airport and transport terminals
    • Highway noise barrier greening
    • School or hospital eco-walls
    • Green commercial signage

    🌟 Benefits of BMP Stainless Steel Green Facade

    • 🏞 Environmental Friendly: Helps plants grow vertically, improving air quality and reducing CO₂.
    • 💧 Weather Resistant: Withstands rain, snow, sunlight, and strong winds.
    • 🔒 Durable: Long service life over 30 years without rust or breakage.
    • 🔥 Thermal Regulation: Reduces building heat in summer and retains warmth in winter.
    • 🎨 Anti-Graffiti: Covers building walls and blocks paint/vandalism.
    • 🍃 Dust Absorption: Green walls absorb nearby dust and exhaust fumes.
    • 🧱 Structural Flexibility: Fits any wall, curve, or shape.
    • 🌿 Visual Harmony: Creates a seamless connection between plants and architecture.

    📦 Packing & Delivery Stainless Steel Green Facade

    • Mesh packed in rolls or panels
    • Inner plastic wrap to prevent scratches
    • Outer sealed in fumigation-free plywood boxes
    • Labels indicate mesh code, 大小, weight, and batch
    • Support custom sizes and container shipment

    💡 Conditions to Consider

    • ✅ Climbing plant species (ivy, wisteria, vines)
    • ✅ Wall direction (south-facing walls grow faster)
    • ✅ Installation frame type (steel tube or wire rope grid)
    • ✅ Environment (coastal, urban, dry, wet)
    • ✅ Rope size vs. mesh opening balance
    • ✅ Anchoring structure strength

    💬 FAQ

    Q1: What wire thickness is best for Stainless Steel Green Facade green walls?
    A1: 1.5 mm or 2.0 mm is most common.

    Q2: Can BMP mesh be installed on existing buildings?
    A2: Yes. It can mount to new or existing surfaces easily.

    Q3: Does the mesh need maintenance?
    A3: No, it’s rustproof and maintenance-free.

    Q4: Can I get custom shape panels?
    A4: Yes. BMP offers custom cutting and shaping.

    Q5: Is black oxide finish available?
    A5: Yes. Available in black, natural silver, or green.

    🌏 Customer Feedback – Australian Project

    “We installed BMP’s Stainless Steel Green Facade mesh for our commercial tower in Sydney. The product looks fantastic, and the plants covered the structure beautifully within two months. 它好強大, polished, and flexible. We’re very happy with the quality and delivery.”
    — Mr. Daniel H., Sydney, Australia

    ✅ Conclusion

    BMP’s Stainless Steel Green Facade is more than a mesh—it’s a living wall system that brings architecture and nature together. With flexibility, 耐久性, rust resistance, and beauty, BMP mesh supports green innovation in all types of projects.

    From skyscrapers to schools, BMP gives you an engineered mesh system that helps the planet and transforms gray into green.
